The electric contact pressure gauge not only has the characteristics of fresh design, reliable layout, complete varieties and specifications, good operation stability, and strong compliance, but also has the advantages of combined measurement and control, simple installation, and small maintenance. Therefore, it is generally not available. An unparalleled pressure measurement and control instrument for a pressure controller with no indication, no switching differential adjustment and no external setting device.
In order to meet the requirements of the tested tools (with requirements such as shock resistance or corrosion resistance and explosion-proof), shock-resistant electric contact pressure gauges or corrosion-resistant electric contact pressure gauges and explosion-proof electric contact pressure gauges that meet the requirements can be selected.
Ordinary type: suitable for measuring the pressure of gases and liquids that have no corrosive effect on copper alloys and iron.
Anti-corrosion type: The main load cell and instrument shell are made of stainless steel material, which is suitable for measuring the pressure of highly corrosive gases and liquids.
Shock-resistant type: By filling the body of the watch with oil and using liquid damping to ensure no vibration performance, it is suitable for measuring violent pulsation of the medium and occasions where the situation is shocking.
Explosion-proof type: It is suitable for injury occasions where there are explosive mixtures.
Placement method
1 Axial with front edge
2 radially infinite
3 Radial belt front
Contact parameters
Working voltage (highest): 380VAC; 220VAC
Maximum working current: 1A
Continuous current; 0.6A
Maximum power: 30W
Working temperature of electric contact pressure gauge: -25℃——55℃
Working pressure upper limit: not more than 2/3 of the upper limit of the instrument
Working conditions, the vibration frequency is not more than 25Hz, and the amplitude is not more than 0.5mm
